- Provides electric stress relief
- Flexible and UV resistant
- Shrink ratio: 3:1
- Minimum full recovery temperature: 120°C
- Standard color: Black
- Compliant with ESI 09-13 standard
- Suitable for insulation applications up to 42 kV
| Size (mm) | Supplied (mm) | Recovery (mm) | Standard length (m) | |
|---|---|---|---|---|
| D* (Min.) | d* (Max.) | w (Min.) | ||
| 35/15 | 35 | 15 | 2.3 | 15m/spool or 1.0-1.5m |
| 55/21 | 55 | 21 | 2.4 | 15m/spool or 1.0-1.5m |
| 75/30 | 75 | 30 | 2.4 | 15m/spool or 1.0-1.5m |
D* = Inner diameter as supplied
d* = Inner diameter after fully recovered
w* = Outer Layer Wall thickness after fully recovered
